3 Axis Large force Electrodynamic Vibrator Shaker Table for
Sinusoidal Vibration Test
Vibration Test System can meet the following test standards:
MIL-STD, DIN, ISO, ASTM, IEC, ISTA, NASA, GB, GJB, JIS, BS etc.
Application
High Frequency Vibration Testing Machine / Vertical Skaker System
Apply For IEC ISTA MIL STD Test Standard adopted the
'double-magnetic circuit structure','self-generated skeleton action
circles', 'Airborne Support' and 'roller bearings and linear
guidance','trunnion isolation' advanced modern technology and
special technology, can be completed in X, Y, Z three-axis
sinusoidal vibration test and broadband random vibration tests, to
be completed by the classical (half - sine) pulse and shock
response spectrum test. It widely used in national defense,
weapons, aviation, aerospace, communications, electronics,
electrical appliances, communications, home appliances and other
fields.
Technical Parameters:
| System Specification |
| System Model: | ES- 60 |
| Frequency Range: | 3~3500 |
| Rated Force | Sine N | 60000 |
| Random N | 60000 |
| Shock N | 120000 |
| Maximum Acc. | sine (m/s2) | 1000 |
| Random (m/s2 rms) | 1000 |
| Shock(m/s2) | 2000 |
| Maximum Vel. | sine (m/s2) | 1.8 |
| Shock(m/s2) | 1.8 |
| Maximum Disp. | Maximum Travel
mm (p-p) | 51 |
| Moving Coil | 60kgs |
| Dimension of moving coil | Dia 40mm |
| Vertical table Size customized | select according to test |
| Horizontal table sizecustomized size | setect according to test |
| Max Load: | 800kgs |
| Name | Packing Vibration Table/Vibration Table Tester for Auto Parts |
| Model | Rated Sine Force (N) | Rated Random Force (N) | Frequency Range (Hz) | Rated Acceleration (m/s2) | Rated Speed(m/s) | Rated displacement (p-p)mm | Max. Loading (Kg) | moving coil (Kg) | Dimension of Moving coil (mm) |
| ES-6 | 6000 | 6000 | 3-3500 | 1000 | 1.6 | 25 | 180 | 6.5 | Φ230 |
| ES-6a | 6000 | 6000 | 3-3500 | 1000 | 1.6 | 51 | 250 | 12 | Φ230 |
| ES-10 | 10000 | 10000 | 3-3000 | 1000 | 1.8 | 51 | 270 | 14 | Φ240 |
| ES-20 | 20000 | 20000 | 3-3000 | 1000 | 1.8 | 51 | 300 | 30 | Φ320 |
| ES-30 | 30000 | 30000 | 3-2800 | 1000 | 1.8 | 5l | 450 | 40 | Φ450 |
| ES-40 | 40000 | 40000 | 3-2800 | 1000 | 1.8 | 51 | 500 | 50 | Φ450 |
| ES-50 | 50000 | 50000 | 3-2700 | 1000 | 1.8 | 51 | 750 | 50 | Φ450 |
| ES-60 | 60000 | 60000 | 3-2700 | 1000 | 1.8 | 51 | 750 | 60 | Φ450 |
| ES-100 | 100000 | 100000 | 3-2500 | 1000 | 1.8 | 51 | 1000 | 90 | Φ450 |
1. Well-designed dynamic circle skeleton, with a higher stage axial
resonance frequency.
2. Two-magnetic circuit, magnetic flux leakage low, compact
structure and rational.
3. Rocker Rod roller bearings straight and import-oriented
composite body stiffness orientation, eccentric load capacity.
4. Trunnion isolation foundation dedicated to hormone use, the
installation of mobile convenience.
5. Advanced technology move around the system to ensure that the
dynamic circle of high reliability.
6. New duct design and enhance the cooling effect.
7. Static stiffness, dynamic stiffness of the bearing small
balloon, raising the vibration table bearing capacity, improve
low-frequency performance.
If you need more information about 3 Axis Large force
Electrodynamic Vibrator Shaker Table for Sinusoidal Vibration Test,
please don't hesitate to send your inquiry.
